盲人磚測試全面解析Comprehensive Test Report on Tactile Paving Tiles

盲人磚測試全面解析
🏆 Pinkerly 盲人磚系列
三種專業設計，滿足不同導向需求：
⚠️ 危險警示型 (Hazard Warning) – 適用於樓梯、斜坡、平台邊緣
➡️ 方向指引型 (Directional) – 適用於行人路徑引導
📍 位置顯示型 (Positional/Oriental) – 適用於設施入口、交叉路口
所有產品均通過國際標準測試認證，品質保證。
📐 精確尺寸，安裝更簡便
測試方法：BS EN ISO 10545-2: 1997
工作尺寸：299 × 299 × 15 mm
平均長寬偏差：< ±0.6%
平均厚度偏差：< ±3%
✅ 精確的尺寸確保安裝無縫銜接
✅ 符合國際標準，保證安裝質量
🛡️ 優異的防滑性能
測試方法：ASTM C1028-07 & AS4586: 2013
乾燥狀態防滑度：0.86-0.93（優秀等級）
潮濕狀態防滑度：0.71-0.75（優秀等級）
鐘擺值防滑度：56-60 BPN
✅ 適合各種室內外環境使用
✅ 有效減少滑倒風險，特別適合公共場所
💧 低吸水率，耐候性強
測試方法：BS EN ISO 10545-3: 1997
危險警示型：2.11%
方向指引型：0.93%
位置顯示型：0.99%
✅ 遠低於標準要求的3%
✅ 低吸水率確保室外使用壽命長，抵抗凍融循環
💪 超高機械強度
測試方法：BS EN ISO 10545-4: 1997
抗折強度：1466-1992 N
破裂模數：36-38 N/mm²
表面硬度：8級（莫氏硬度）
✅ 承受高流量行人使用
✅ 堅固耐用，安裝後不易破損
🧪 全面耐化學性
測試方法：BS EN ISO 10545-13: 1997
家用化學品：UA級（無影響）
游泳池鹽類：UA級（無影響）
酸鹼物質：ULA/UHA級（無影響）
✅ 抗各種化學物質侵蝕，維護簡單
✅ 適用於需要頻繁清潔的公共場所
✨ 完美表面質量
測試方法：BS EN ISO 10545-2: 1997
100%無缺陷
耐汙漬能力：5級（最高級）
表面平整度：符合±0.5%標準
✅ 表面光滑均勻，觸感辨識清晰
✅ 長期使用外觀如新，提供穩定的觸覺反饋
🔄 卓越耐磨能力
測試方法：BS EN ISO 10545-6: 1997
深磨損體積：121.3 mm³
標準上限：175 mm³
✅ 優異的耐磨性能，適合高客流量區域
✅ 長期使用後仍保持清晰的觸覺辨識紋路
🌡️ 穩定的耐熱震性能
測試方法：BS EN ISO 10545-9: 1996
10輪熱冷循環後無可見缺陷
平均吸水率：<1%
✅ 優異耐熱震性，適應溫度急劇變化環境
✅ 即使經歷陽光暴曬後突遇降雨也不會開裂
✅ 熱脹冷縮性能穩定，適合室外全天候使用
📊 精確的形狀控制
測試方法：BS EN ISO 10545-2: 1997
直線度偏差：≤±0.2%
矩形度偏差：≤±0.4%
✅ 精確的形狀確保安裝美觀、密實
✅ 減少安裝時間和浪費，提高工程效率
🔍 為何選擇大方公司盲人磚？
✅ 已通過香港政府部門認可(HOKLAS)實驗室測試
✅ 所有測試均採用國際標準方法
✅ 確保每塊磚材都符合嚴格的質量要求
✅ 高度安全防滑設計
✅ 出色的抗污及耐化學性
✅ 尺寸精確，施工快速方便
✅ 持久耐用、易維護清潔
為視障人士提供安全可靠的引導系統，是我們的使命。
📱 想了解更多產品資訊？
歡迎隨時聯絡我們！
大方公司
專注香港工程40年
大方公司 Tai Fong Co. (Tiles & Granite)
建築材料供應商(磚瓦及麻石)

Comprehensive Test Report on Tactile Paving Tiles

🏆 Pinkerly Tactile Paving Series
Three specialized designs to meet different orientation needs:
⚠️ Hazard Warning Type – For stairs, ramps, and platform edges
➡️ Directional Type – For guiding pedestrian pathways
📍 Positional/Orientational Type – For facility entrances and intersections

All products are certified through international testing standards, ensuring uncompromised quality.

📐 Precision Dimensions for Easy Installation

Test Method: BS EN ISO 10545-2:1997

  • Working size: 299 × 299 × 15 mm

  • Average length/width deviation: < ±0.6%

  • Average thickness deviation: < ±3%

✅ Accurate sizing guarantees seamless installation
✅ Meets international standards for assured quality

🛡️ Outstanding Slip Resistance

Test Methods: ASTM C1028-07 & AS 4586:2013

  • Dry condition: 0.86–0.93 (Excellent)

  • Wet condition: 0.71–0.75 (Excellent)

  • Pendulum Test Value (BPN): 56–60

✅ Suitable for indoor and outdoor applications
✅ Effectively reduces slip risk in public areas

💧 Low Water Absorption, Strong Weather Resistance

Test Method: BS EN ISO 10545-3:1997

  • Hazard Warning Type: 2.11%

  • Directional Type: 0.93%

  • Positional Type: 0.99%

✅ Far below the standard requirement of 3%
✅ Ensures long outdoor lifespan, resistant to freeze-thaw cycles

💪 Exceptional Mechanical Strength

Test Method: BS EN ISO 10545-4:1997

  • Bending strength: 1466–1992 N

  • Modulus of rupture: 36–38 N/mm²

  • Surface hardness: Mohs scale 8

✅ Withstands heavy pedestrian traffic
✅ Highly durable and resistant to breakage

🧪 Excellent Chemical Resistance

Test Method: BS EN ISO 10545-13:1997

  • Household chemicals: Grade UA (Unaffected)

  • Swimming pool salts: Grade UA (Unaffected)

  • Acids & alkalis: Grades ULA/UHA (Unaffected)

✅ Resistant to chemical corrosion
✅ Ideal for public facilities requiring frequent cleaning

✨ Superior Surface Quality

Test Method: BS EN ISO 10545-2:1997

  • 100% defect-free surface

  • Stain resistance: Grade 5 (highest level)

  • Surface flatness: within ±0.5% standard

✅ Smooth, uniform finish with clear tactile feedback
✅ Maintains appearance and function even after long-term use

🔄 Excellent Abrasion Resistance

Test Method: BS EN ISO 10545-6:1997

  • Deep abrasion volume: 121.3 mm³

  • Standard limit: 175 mm³

✅ Superior wear resistance for high-traffic areas
✅ Tactile patterns remain sharp and effective over time

🌡️ Stable Thermal Shock Resistance

Test Method: BS EN ISO 10545-9:1996

  • 10 heat-cold cycles with no visible defects

  • Average water absorption: <1%

✅ Withstands sudden temperature changes
✅ No cracking under sun exposure followed by rainfall
✅ Stable thermal expansion, ideal for all-weather outdoor use

📊 Accurate Shape Control

Test Method: BS EN ISO 10545-2:1997

  • Straightness deviation: ≤ ±0.2%

  • Rectangularity deviation: ≤ ±0.4%

✅ Ensures neat, compact installation
✅ Reduces installation time and waste, improving efficiency

🔍 Why Choose Tai Fong Company Tactile Tiles?

✅ Certified by HOKLAS-accredited laboratories recognized by the Hong Kong Government
✅ All testing conducted using international standards
✅ Every tile meets strict quality requirements
✅ Excellent anti-slip safety design
✅ Superior stain and chemical resistance
✅ Precision dimensions for efficient installation
✅ Long-lasting durability and easy maintenance

Providing a safe and reliable guidance system for the visually impaired is our mission.

📱 Want to learn more about our products?
Feel free to contact us!

Tai Fong Company
Serving Hong Kong projects for 40 years
Tai Fong Co. (Tiles & Granite) – Specialist in Building Materials (Tiles & Granite)
